- Base unit
- PCE
- Special features
- Synchronization, Pushbutton
- EAN/UPC code
- 4047101287318
- Function
- Level detection, Continuous level measurement
- Detection type
- contactless
- Gross weight
- 160
- Height
- 3
- Length
- 9
- Net weight
- 160
- Dimension unit
- MMT
- Weight unit
- GRM
- Volume
- 0.081
- Volume unit
- CMQ
- Width
- 3
- Ambient temperature max. (°C)
- 70
- Ambient temperature min. (°C)
- -25
- Communication protocol
- IO-Link
- Electrical connection
- Connector
- Connector type
- M12 x 1
- Design
- Threaded barrel
- Construction size
- ⌀ 30 mm
- Dimensions
- 89 mm
- Housing material
- Metal
- Housing quality
- CuZn
- Housing surface
- Nickel Plated
- Medium
- liquids, Bulk goods
- Function
- Proximity switch
- Operating mode
- Time-of-Flight
- Output function
- PNP/NPN, analog output
- Measuring principle
- Ultrasonic
- Protection class
- IP67
- Quality active face
- Epoxy
- Max. range (mm)
- 3000
- Resolution
- 1 cm
- Setting option
- Push Button, Remote Teach, IO-Link
- Switching element function
- NO/NC
- Radiation direction
- straight
