Pressure Transmitter
PT60R-2001-U1-H1143/X
Order ID no. 6837628
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101402421
Electrical output
Voltage output (3-wire)
Gross weight
90
Height
0
Length
0
Net weight
90
Dimension unit
MMT
Weight unit
GRM
Volume
0
Width
0
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Approvals
cULus
Electrical connection
Connector
Connector type
M12 x 1
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4016 (AISI 430)
Process connection
G 1/4” female thread (front sealing)
Media temperature max. (°C)
135
Media temperature min. (°C)
-40
Pressure range
0...60 bar
Operating voltage
DC
Output function
Analog output voltage
Pressure type
Relative pressure
Protection class
IP67
Key Features
Electrical output
Voltage output (3-wire)
Process connection
G 1/4” female thread (front sealing)
In Stock
Price Group
J1
List Price
$153.99
