PT600R-2119-I2-MP11 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT600R-2119-I2-MP11
Order ID no. 100003602
home
Home
Loading...
Technical Data
Downloads
Electrical output
Current output (2-wire)
Ambient temperature max. (°C)
100
Ambient temperature min. (°C)
-40
Electrical connection
Connector
Connector type
Metri Pack 150 P2S series
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Process connection
M14 x 1.5 male thread
Media temperature max. (°C)
125
Media temperature min. (°C)
-40
Pressure range
0...600 bar
Operating voltage
DC
Output function
Analog output current
Pressure type
Relative pressure
Protection class
IP67
Key Features
Electrical output
Current output (2-wire)
Process connection
M14 x 1.5 male thread
In Stock
Price Group
J1
List Price
$162.96
