Flow Monitoring
FCS-HA2P-VRX/24VDC/AL115 6M
Order ID no. 6870725
In Stock
Price Group
D2
List Price
$693.99
Item Total
$693.99
Quantity
−
+
add_shopping_cart
Add to Cart
home
Turck-Shop
Sensors
Flow Sensors/Flow Meters
FCS-HA2P-VRX/24VDC/AL115 6M
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101175257
Function
Flow monitoring
Detection type
Calorimetric
Gross weight
903
Height
60
Length
190
Net weight
903
Dimension unit
MMT
Weight unit
GRM
Volume
1368
Volume unit
CMQ
Width
120
Cable length (m)
6
Electrical connection
Cable
Design
Immersion
Housing material
Plastic
Housing quality
PBT-GF30-V0
Process connection
G 1” female thread DIN 3852
Medium
gases
Media temperature max. (°C)
80
Media temperature min. (°C)
-20
Mounting conditions
Immersion sensor
Operating voltage
DC
Output function
Relay output
Protection class
IP68
Switching element function
Complementary contact
Key Features
Process connection
G 1” female thread DIN 3852
Output function
Relay output
