FCI-D10A4P-LIX-H1141/A | TURCK - Your Global Automation Partner
Flow Monitoring
FCI-D10A4P-LIX-H1141/A
Order ID no. 6870639
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101174588
Function
Flow monitoring
Detection type
Calorimetric
Gross weight
310
Height
50
Length
110
Net weight
310
Dimension unit
MMT
Weight unit
GRM
Volume
605
Volume unit
CMQ
Width
110
Ambient temperature max. (°C)
60
Ambient temperature min. (°C)
0
Application area
Standard
Approvals
cULus
Electrical connection
Connector
Connector type
M12 x 1
Design
Inline
Housing material
Plastic
Housing quality
PBT
Process connection
G 1/4''
Medium
gases
Media temperature max. (°C)
80
Media temperature min. (°C)
0
Mounting conditions
Inline sensor
Operating voltage
DC
Output function
Analog output
Protection class
IP67
Key Features
Process connection
G 1/4''
Output function
Analog output
In Stock
Price Group
D2
List Price
$979.55
