FCS-GL1/2A4-NA-H1141 | TURCK - Your Global Automation Partner
Flow Monitoring
FCS-GL1/2A4-NA-H1141
Order ID no. 6870403
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101173567
Function
Flow monitoring
Detection type
Calorimetric
Gross weight
190
Height
50
Length
120
Net weight
190
Dimension unit
MMT
Weight unit
GRM
Volume
660
Volume unit
CMQ
Width
110
Application area
Standard
Electrical connection
Connector
Connector type
M12 x 1
Design
Immersion
Dimensions
121,1 mm x 38 mm x 49 mm
Display
4-digit 12-segment display, rotatable by 180°, red or green
Housing material
Stainless steel
Housing quality
1.4571 (AISI 316Ti)
Process connection
G 1/2” long version
Medium
liquids
Media temperature max. (°C)
80
Media temperature min. (°C)
-20
Mounting conditions
Immersion sensor
Protection class
IP67
Key Features
Process connection
G 1/2” long version
In Stock
Price Group
D2
List Price
$394.23
home
Turck-Shop
Sensors
Flow Sensors/Flow Meters
FCS-GL1/2A4-NA-H1141
Item Total
$394.23
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
