FCS-G1/2A4-NAEX0-H1141/L065 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Flow Monitoring
FCS-G1/2A4-NAEX0-H1141/L065
Order ID no. 6870375
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101173390
Function
Flow monitoring
Detection type
Calorimetric
Gross weight
208
Height
60
Length
130
Net weight
208
Dimension unit
MMT
Weight unit
GRM
Volume
780
Volume unit
CMQ
Width
100
Application area
Explosion hazard (zone 0)
Approvals
ATEX, CE, UKCA, GOST
Electrical connection
Connector
Connector type
M12 x 1
Design
Immersion
Housing material
Stainless steel
Housing quality
1.4571 (AISI 316Ti)
Process connection
G 1/2''
Medium
liquids
Media temperature max. (°C)
60
Media temperature min. (°C)
-20
Mounting conditions
Immersion sensor
Protection class
IP67
Key Features
Process connection
G 1/2''
In Stock
Price Group
D2
List Price
$1,045.41
