FCS-G3/4A4-NAEX/L100/D100 | TURCK - Your Global Automation Partner
Flow Monitoring
FCS-G3/4A4-NAEX/L100/D100
Order ID no. 6870371
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101173352
Function
Flow monitoring
Detection type
Calorimetric
Gross weight
442
Height
40
Length
220
Net weight
442
Dimension unit
MMT
Weight unit
GRM
Volume
792
Volume unit
CMQ
Width
90
Ambient temperature max. (°C)
120
Ambient temperature min. (°C)
10
Application area
High temperature
Approvals
ATEX, CE, UKCA, GOST
Cable color
Blue
Cable length (m)
2
Electrical connection
Cable
Design
Immersion
Housing material
Stainless steel
Housing quality
1.4571 (AISI 316Ti)
Process connection
G 3/4''
Medium
liquids
Media temperature max. (°C)
120
Media temperature min. (°C)
10
Mounting conditions
Immersion sensor
Protection class
IP67
Key Features
Process connection
G 3/4''
In Stock
Price Group
D2
List Price
$1,653.41
