FCS-GL1/2A4-NAEX0-H1141/A | TURCK - Your Global Automation Partner
Flow Monitoring
FCS-GL1/2A4-NAEX0-H1141/A
Order ID no. 6870348
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101173123
Function
Flow monitoring
Detection type
Calorimetric
Gross weight
176
Height
50
Length
110
Net weight
176
Dimension unit
MMT
Weight unit
GRM
Volume
605
Volume unit
CMQ
Width
110
Application area
Explosion hazard (zone 0)
Approvals
ATEX, CE, UKCA, GOST
Electrical connection
Connector
Connector type
M12 x 1
Design
Immersion
Housing material
Stainless steel
Housing quality
1.4571 (AISI 316Ti)
Process connection
G 1/2” long version
Medium
gases
Media temperature max. (°C)
60
Media temperature min. (°C)
-20
Mounting conditions
Immersion sensor
Protection class
IP67
Key Features
Process connection
G 1/2” long version
In Stock
Price Group
D2
List Price
$775.52
