Home
Products

BCT10-S30-UN6X2-H1151 | TURCK - Your Global Automation Partner

Capacitive Sensor

BCT10-S30-UN6X2-H1151

Order ID no. 2101800

homeHome
Loading...

Base unit: PCE
EAN/UPC code: 4047101332803
Gross weight: 66
Height: 30
Length: 100
Net weight: 66
Dimension unit: MMT
Weight unit: GRM
Volume: 300
Volume unit: CMQ
Width: 100
Ambient temperature max. (°C): 70
Ambient temperature min. (°C): -25
Approvals: UL
Communication protocol: IO-Link
Electrical connection: Connector
Connector type: M12 x 1
Design: Threaded barrel
Construction size: ⌀ 30 mm
Dimensions: 87,3 mm
Housing material: Plastic
Housing quality: PA12-GF30, PEI
Mounting conditions: Flush
Operating voltage: DC
Output function: NPN
Measuring principle: Capacitive
Protection class: IP67, IP69K
Quality active face: PA12-GF30
Rated switching distance (mm): 15
Switching element function: NO/NC
Switching frequency (kHz): 0.01

homeTurck-Shop
Sensors
Capacitive Sensors
BCT10-S30-UN6X2-H1151

Key Features

Electrical connection: Connector
Mounting conditions: Flush
Output function: NPN
Rated switching distance (mm): 15

In Stock
Price Group	E1
List Price	$267.15

Item Total$267.15

Quantity

Contact Support
